NATURE COMMUNICATIONS | https://doi.org/10.1038/s41467-020-20334-6 ARTICLE and the reflected images of the electrode surface were obtained. The setup diagram is shown in Fig. 3a. The imaging area was 200–400 μm away from the top elec- trode’s projection. Different current densities (5–80 mA cm−2) were applied, and four electrolytes (Electrolyte 1: 2 M ZnSO4 in seawater; Electrolyte 2: 2 M ZnSO4 with 0.1 M MnSO4 in seawater; Electrolyte 3: 2 M ZnSO4 with 0.1 M MnSO4 in DI water; Electrolyte 4: 2 M ZnSO4 in DI water) were tested to investigate the Zn plating process. To compare with the 3D Zn-Mn alloy, a pristine Zn foil anode was also tested in Electrolyte 2. After the Zn plating, the current density of 80 mA cm−2 was used to analyze the stripping process of the 3D Zn-Mn anode. DFT calculations. Density functional theory (DFT) simulation was conducted to analyze the adsorption and kinetics of Zn ad-atoms on the experimentally con- firmed Zn3Mn (110) surface. For the simplicity and the efficiency of the calculation, the simulation was conducted on the cubic cell to extract the effect of Mn sub- stitution alone. The simulation model was constructed with 40 Zn and 16 Mn atoms in a unit cell of 1.08 × 0.76 × 2.08 nm. The x, y, and z directions of the cell correspond to [001], [1–10], and [110] crystal orientation, respectively. A vacuum layer of 1.2 nm was included in the z-direction to avoid the interaction from the neighboring cells in a periodic boundary condition. Vienna Ab-initio Simulation Package (VASP) was used in the calculation63,64, with projector augmented wave (PAW) pseudopotential65,66 and generalized gradient approximation by Perdew- Burke-Ernzerhof67. The plane wave energy cut off was 400 eV and 3 × 5 × 1 k-points were selected based on the Monkhorst-Pack method68. First, the conjugate gradient structure optimization was performed while fixing the atoms in the bottom two layers. Then, a Zn atom was placed on the surface at 10 × 10 grid points and structural optimization was performed. Here only the ad-atom was relaxed in z-direction while fixing the x and y coordinates. Also, a Zn ad-atom was placed on a surface lattice point and structure optimization was conducted to calculate the binding energy. The binding energy calculation was also performed on the Zn (110) surface for comparison. The binding energies were calculated by the (total energy of the system w/o Zn ad-atom) + (isolated Zn atom) – (total energy of the model w/ Zn ad-atom). Data availability The data that support the findings of this study are available from the corresponding author upon reasonable request. Received: 9 October 2020; Accepted: 26 November 2020; References 1. Armand, M. & Tarascon, J. M. Building better batteries. Nature 451, 652–657 (2008). 2. Pan, H. L. et al. Reversible aqueous zinc/manganese oxide energy storage from conversion reactions. Nat. Energy 1, 16039 (2016). 3. Tang, B. Y., Shan, L. T., Liang, S. Q. & Zhou, J. Issues and opportunities facing aqueous zinc-ion batteries. Energy Environ. Sci. 12, 3288–3304 (2019). 4. Higashi, S., Lee, S. W., Lee, J. S., Takechi, K. & Cui, Y. Avoiding short circuits from zinc metal dendrites in anode by backside-plating configuration. Nat. Commun. 7, 11801 (2016). 5. Deng, Y.-P. et al. The current state of aqueous Zn-based rechargeable batteries. ACS Energy Lett. 5, 1665–1675 (2020). 6. Hopkins, B. J., Shao-Horn, Y. & Hart, D. P. Suppressing corrosion in primary aluminum–air batteries via oil displacement. Science 362, 658–661 (2018). 7. Li, C.-S., Sun, Y., Gebert, F. & Chou, S.-L. Current progress on rechargeable magnesium–air battery. Adv. Energy Mater. 7, 1700869 (2017). 8. Li, Y. & Lu, J. Metal–air batteries: will they be the future electrochemical energy storage device of choice? ACS Energy Lett. 2, 1370–1377 (2017). 9. Lu, Y. Y., Tu, Z. Y. & Archer, L. A. Stable lithium electrodeposition in liquid and nanoporous solid electrolytes. Nat. Mater. 13, 961–969 (2014). 10. Ma, J. L. et al. Prevention of dendrite growth and volume expansion to give high-performance aprotic bimetallic Li-Na alloy-O2 batteries. Nat. Chem. 11, 64–70 (2019). 11. Wang, F. et al. Highly reversible zinc metal anode for aqueous batteries. Nat. Mater. 17, 543–549 (2018). 12. Davidson, R. et al. Formation of magnesium dendrites during electrodeposition. ACS Energy Lett. 4, 375–376 (2019). 13. Xiao, N., McCulloch, W. D. & Wu, Y. Reversible dendrite-free potassium plating and stripping electrochemistry for potassium secondary batteries. J. Am. Chem. Soc. 139, 9475–9478 (2017). 14. Li, Y. Z. et al. Atomic structure of sensitive battery materials and Interfaces revealed by cryo-electron microscopy. Science 358, 506–510 (2017). 15. Zhu, M. Q. et al. Homogeneous guiding deposition of sodium through main group II metals toward dendrite-free sodium anodes. Sci. Adv. 5, eaau6264 (2019). 16. 17. 18. 19. 20. 21. 22. 23. 24. 25. 26. 27. 28. 29. 30. 31. 32. 33. 34. 35. 36. 37. 38. 39. 40. 41. 42. 43. 44. 45. 46. Zheng, J. X. et al. Reversible epitaxial electrodeposition of metals in battery anodes. Science 366, 645–648 (2019). Parker, J. F. et al. Rechargeable nickel–3D zinc batteries: an energy-dense, safer alternative to lithium-ion. Science 356, 415 (2017). Kang, L. et al. Nanoporous CaCO3 coatings enabled uniform Zn stripping/ plating for long-life zinc rechargeable aqueous batteries. Adv. Energy Mater. 8, 1801090 (2018). Choudhury, S. et al. Designing solid-liquid interphases for sodium batteries. Nat. Commun. 8, 898 (2017). Zhang, X. Y., Wang, A. X., Liu, X. J. & Luo, J. Y. Dendrites in lithium metal anodes: suppression, regulation, and elimination. Acc. Chem. Res. 52, 3223–3232 (2019). Suo, L. et al. “Water-in-salt” electrolyte enables high-voltage aqueous lithium- ion chemistries. Science 350, 938 (2015). Suo, L. et al. Advanced high-voltage aqueous lithium-ion battery enabled by “water-in-bisalt” electrolyte. Angew. Chem. Int. Ed. 55, 7136–7141 (2016). Yang, C. et al. Aqueous Li-ion battery enabled by halogen conversion–intercalation chemistry in graphite. Nature 569, 245–250 (2019). Yan, J. et al. Rechargeable hybrid aqueous batteries. J. Power Sources 216, 222–226 (2012). Yamada, Y. et al. Hydrate-melt electrolytes for high-energy-density aqueous batteries. Nat. Energy 1, 16129 (2016). Ye, H. et al. Guiding uniform Li plating/stripping through lithium-aluminum alloying medium for long-life Li metal batteries. Angew. Chem. Int. Ed. 58, 1094–1099 (2019). Kong, L.-L. et al. Lithium–magnesium alloy as a stable anode for lithium–sulfur battery. Adv. Funct. Mater. 29, 1808756 (2019). Ding, F. et al. Dendrite-free lithium deposition via self-healing electrostatic shield mechanism. J. Am. Chem. Soc. 135, 4450–4456 (2013). Chen, P.-Y. & Hussey, C. L. The electrodeposition of Mn and Zn–Mn alloys from the room-temperature tri-1-butylmethylammonium bis ((trifluoromethane)sulfonyl)imide ionic liquid. Electrochim. Acta 52, 1857–1864 (2007). Jaber, A. Y., Alamri, S. N. & Aida, M. S. CdS thin films growth by ammonia free chemical bath deposition technique. Thin Solid Films 520, 3485–3489 (2012). Costovici, S., Manea, A.-C., Visan, T. & Anicai, L. Investigation of Ni-Mo and Co-Mo alloys electrodeposition involving choline chloride based ionic liquids. Electrochim. Acta 207, 97–111 (2016). Wang, H. et al. Engineering Fe–Fe3C@Fe–N–C active sites and hybrid structures from dual metal–organic frameworks for oxygen reduction reaction in H2–O2 fuel cell and Li–O2 battery. Adv. Funct. Mater. 29, 1901531 (2019). Shi, Y. et al. A tunable 3D nanostructured conductive gel framework electrode for high-performance lithium ion batteries. Adv. Mater. 29, 1603922 (2017). Yuksel, R., Buyukcakir, O., Seong, W. K. & Ruoff, R. S. Metal-organic framework integrated anodes for aqueous zinc-ion batteries. Adv. Energy Mater. 10, 1904215 (2020). Uthaisar, C. & Barone, V. Edge effects on the characteristics of Li diffusion in graphene. Nano Lett. 10, 2838–2842 (2010). Persson, K., Hinuma, Y., Meng, Y. S., Van der Ven, A. & Ceder, G. Thermodynamic and kinetic properties of the Li-graphite system from first- principles calculations. Phys. Rev. B 82, 125416 (2010). Mandeltort, L. & Yates, J. T. Rapid atomic Li surface diffusion and intercalation on graphite: a surface science study. J. Phys. Chem. C 116, 24962–24967 (2012). Politano, A. et al. Photothermal membrane distillation for seawater desalination. Adv. Mater. 29, 1603504 (2017). Fridman-Bishop, N., Nir, O., Lahav, O. & Freger, V. Predicting the rejection of major seawater ions by spiral-wound nanofiltration membranes. Environ. Sci. Technol. 49, 8631–8638 (2015). Bi, H. et al. A universal approach to aqueous energy storage via ultralow-cost electrolyte with super-concentrated sugar as hydrogen-bond-regulated solute. Adv. Mater. 32, 2000074 (2020). Fashu, S. et al. Electrodeposition, morphology, composition, and corrosion performance of Zn-Mn coatings from a deep eutectic solvent. J. Mater. Eng. 24, 434–444 (2015). Xie, X. et al. Manipulating the ion-transfer kinetics and interface stability for high-performance zinc metal anodes. Energy Environ. Sci. 13, 503–510 (2020). Pei, A., Zheng, G., Shi, F., Li, Y. & Cui, Y. Nanoscale nucleation and growth of electrodeposited lithium metal. Nano Lett. 17, 1132–1139 (2017). Lin, C.-H. et al. Systems-level investigation of aqueous batteries for understanding the benefit of water-in-salt electrolyte by synchrotron nanoimaging. Sci. Adv. 6, eaay7129 (2020). Lee, D. U., Choi, J.-Y., Feng, K., Park, H. W. & Chen, Z. Advanced extremely durable 3D bifunctional air electrodes for rechargeable zinc-air batteries. Adv. Energy Mater. 4, 1301389 (2014). Xiao, W. P. et al. Atomic rearrangement from disordered to ordered Pd-Fe nanocatalysts with trace amount of Pt decoration for efficient electrocatalysis. Nano Energy 50, 70–78 (2018). NATURE COMMUNICATIONS | (2021)12:237 | https://doi.org/10.1038/s41467-020-20334-6 | www.nature.com/naturecommunications 11PDF Image | high-performance dendrite-free seawater-based batteries
