Figure 2.3 Photos of the set-up for column experiments The area under breakthrough curve was calculated with numerical integration by Trapezoidal Rule. The capacity of the beads were found by subtracting the area from the total amount of lithium fed to the column. 2.3 Equipment 2.3.1 Measurement of metal ion concentration in aqueous solutions Lithium, sodium, potassium, magnesium and calcium contents in aqueous solutions were measured by the aid of Shimadzu Atomic Absorbance Spectrophotometer using acetylene as a fuel. Lithium, sodium and potassium ions were measured by emission technique while others were measured by absorbance using specialized lamps. Each individual metal ion concentration was measured by first constructing a calibration curve with metal ion solutions at known concentrations. 35PDF Image | SEPARATION OF LITHIUM FROM BRINES
