1 • Hot brine extracted from the ground and generates steam that powers turbines and produces renewable electricity • Brine flow is diverted, and lithium is extracted from the solution with a Direct Lithium Extraction (DLE) process. • Lithium chloride sent to lithium refining plant which will be converted LiCl to battery quality LiOH • Water is recycled, no toxic wastes, no gases are emitted, heat and power from renewable resources, no fossil fuels are burnt Process flow sheet25 Brine feed From 5 plants Brine to reinjection Geothermal Plant Vulcan has IP protection around flowsheet Geothermal Plant Make-up water Eluate DLE Plant Pre-treatment Direct Lithium Extraction Post-treatment Eluate Concentration Impurity removal Electrolysis Central Lithium Plant HCI synthesis LHM production 2 3 Battery grade LHM product Hydrochloric acid (HCI) conc. 21PDF Image | Direct Lithium Extraction
